Prime PRIMAVERA - Carbon 3 Headset Technical Manual

HEADSET TECHNICAL MANUAL
CARBON 3
1-1/8"+1.5" Tapered Integrated Headset w/ Carbon Top Cover
56±0.1
42
52.1
46±0.1
3.0
+0.1
0
7.5
0
-0.2
+0.05
0
0
-0.2
33
1
No. Item
Q'ty
1 Top Cover 1
2
Compression Ring
1
3
1
4
1
5 Crown Race
1
Headtube OD: 46mm Upper / 56mm Lower
Fork Steerer: 1-1/8" to 1.5" Tapered
Bearing: TS Bearings
4
5
Stack Height: 2.9+1 = 3.9mm
Unit: mm Scale: 1:1
7
51.8
45°
45°
1
2
3
6.5
41.8
45°
45°
0.5
28.6
+0.1
-0
39.8
+0.1
-0
2.9
Upper Bearing IS42/28.6
Lower Bearing IS52/39.8
