8
6. Using the Ratchet ring removal tool, slide this onto the hub and position within the ratchet ring. Clamp the area of
the tool highlighted in red in a vice. Gripping the rim firmly and using it as leverage turn the wheel counter-clockwise
until the ratchet ring is fully unwound. Please note that this will be tight due to being self tightening and may take
force to loosen.
7. Once the ratchet ring is removed, slide off the ratchet washer.
