3、As shown in Figure 3-1, there are two layers between the door bracket and the rubber
bumper, the middle glass can be inserted into the empty area between the two layers. For
removal of the middle glass, user can refer to step 1 and step 2 shown in Figure 3-2, remove
the middle glass in layer 1 first, then follow the step 1 and step 2 shown in Figure 3-3 to
remove the middle glass in layer 2. After cleaning of the middle glasses, assemble the middle
glass in layer 2 and also the rubber bumper first, then assemble the middle glass in layer 1.
Check if the bumpers are well positioned after the installation of middle glass as shown in
Figure 3-1. In case if there is only 1 middle glass, then assemble the middle glass in layer 1.
Figure3-1
Figure 3-2 Figure 3-3
4、After installation of middle glass, follow step 2 to insert the inner glass from the oven door
top cover, press the inner glass after positioning to make the clip spring to be inserted to the
socket completely.
5、Assemble the door back the oven, stir the toggle cover of the hinges back, close the oven
door.
Layer1 Layer2
1
2
1
2
9
