10
13000LBS FEATURES AND SPECIFICATIONS
Single Line Rated Pull 13000lb(5900kg) single line
Motor 12V 5.5hp/4.0kw,24V 6.44hp/4.8kw Series Wound
Control Remote Switch,12ft(3.7m)lead
Gear train 3 Stage Planetary
Gear reduction ration 218.4:1
Clutch flexible operation,water-resistent
Braking Action Automatic In-The-Drum
Drum Size
Φ64mmxL223mm
Cable
Φ9.5mm, 26m
Fairlead 4-Way Roller Fairlead
Remote Control Included
Battery Recommended:650CCA minimum for winching
Battery Leads 2 gauge,72"(183mm)
Finish Dark gray powder coat
Overall Dimensions 21.3"x6.3"x8.6"(540mmx160mmx218mm)
Mounting Bolt Pattern 254mmx114.3mm(10"x4.5")
Weight N.W:36kg G.W: 38Kg
Packing size 57x19x34.5cm 1PC/CTN
12V LINE SPEED ANDAMP DRAW(FIRST LAYER)
Line Pull(lbs./kg) Line Speed
FPM(m/min)
Motor(Amps)
0 22.5ft(6.85m) 65
2000(907) 12.4ft(3.8m) 110
4000(1814) 9.8ft(3.0m) 165
6000(2721) 8.5ft(2.6m) 220
8000(3628) 7.5ft(2.3m) 270
10000(4536) 6.56ft(2.0m) 340
13000(5900) 4.8ft(1.48m) 430
24V LINE SPEED ANDAMP DRAW(FIRST LAYER)
Line Pull(lbs./kg) Line Speed
FPM(m/min)
Motor(Amps)
0 24.86ft(7.85m) 52
2000(907) 12.79ft(3.9m) 107
4000(1814) 10.23ft(3.12m) 146
6000(2721) 8.79ft(2.68m) 178
8000(3628) 8.04ft(2.45m) 205
10000(4536) 6.89ft(2.1m) 235
13000(5900) 5.12ft(1.56m) 305
