12
13000LBS LINE PULL AND CABLE CAPACITY
Layer of cable 1 2 3 4
13000 10010 8840 7410 Rated line
pull per layer
5900 4541 4010 3361
15 34.6 58.6 85.3 Cumulative
cable capacity
4.58 10.54 17.87 26
16800LBS LINE PULL AND CABLE CAPACITY
Layer of cable
1 2
3 4
16800 13779 13779 11202 9358
Rated line
pull per layer
7620 6250 6250 5081 4245
16.64 37.78 37.78 63.40 91.86
Cumulative
cable capacity
5.1 11.5 11.5 19.3 28
13000LBS/16800LBS WINCH PARTS LIST
Item
No.
Part No. Description Qty
Item
No.
Part No. Description Qty
1 0107/08-01 Transmission Shaft 1 14 0107/08-15 Sealing Ring 2
2 0115/16-02 Fixed Screw 1 15 0107/08-16A Nylon Bearing 1
3 0107/08-24 Gear Box 1 16 0107/08-25A Brake 1
4 0107/08-04 Clutch Handle 1 17 0107/08-18
Gear-Box
Bracket
1
5 0115/16-06 Clutch Gear 1 18 0107/08-19
Mounting Bolt
M12x35
4
6 0107/08-07 Drum 1 19 0107/08-20 Sealing Ring 1
7 0107/08-08 Tie Bar 2 20 0115/16-21
Gear Carrier
Ass y-output
1
8 0115/16-09 Connecting Shaft 1 21 0115/9-22
Gear Carrier
Ass
y-intermediate
1
9 0107/08-10
Torque Overload
Protection
1 22 0115/16-23
Gear Carrier
Ass y-Input
1
10 0107/08-11 Lining 1 23 0115/16-50 Sun Gear-Input 1
0115/16-12 Motor(12V) 1 24 0115/08-26 Bearing 1
11
0115/1612A Motor(24V) 1 25 0107/08-27 Roller Fairlead 1
12 10107/08-13 Link Screw M8x25 4 26 0107/08-28 Hook 1
13 0107/08-14 Motor Bracket 1 27 0113-14-29 Wire rope 1
To Next Page
