PSS500 CONTROL BOARD JUMPERS - FIELD CONFIGURATION
(CONTINUED)
Step 10 Firmly press down on the SBC196 board unit it is correctly seated.
Step 11 Attach the four nylon washers and small nuts to the stand-offs.
Step 12 Attach the ribbon cable to the SBC196 board with the red stripe at
the top of the outer socket (where the yellow capacitor is located).
Be careful not to bend any pins when re-attaching the cable end.
Step 13 Verify all connections are secure.
Step 14 Return power to the control board.
Additional Information
For further information and photographs, refer to PRIMUS DYK #202 - PSS5
Control Board Jumper Configuration and DYK #238 - PSS500 Controller
Components #5 – Interface Board Jumpers.
