PAGE 4
076/0705500
Copyright © Prins Autogassystemen B.V. 2014
Tightening moments
Spanner mm
M 4 x 0,7
7
M 5 x 0,8
8
M 6 x 1,0
10
M 7 x 1,0
11
M 8 x 1
13
M 8 x 1,25
13
M 10 x 1
15-16-17
M 10 x 1,5
15-16-17
( filtered ) Banjo bolt
14
Supply line connection
13
Fuel module Allen bolts
7
Filler hose connection
22
Boost pump clamp
10
High pressure petrol fuel line
17
EXPLANATION OF SYMBOLS :
= IMPORTANT, CAUTION
= WEAR SAFETY GOGGLES
