Machine cleaning
4. Dust bucket reset:
A. Turn the cyclone cone into the filter component clockwise, according to the direction
of the arrow filter into the dust cup, filter component raised reinforcement positioning
shape at the dust cup inlet positioning shape, counterclockwise rotation hear click
installed in place, and then put the wind in the direction of the arrow dust cup in the
direction of the arrow.
B. Hold the host, press the opposite direction of the removal dust cup assembly, align
the dust cup limit slot on the dust cup at the host limit point, press the arrow dust cup
up to the upper dust cup, rotate the dust cup counterclockwise and install in place.
5. Clean out the wind: as shown in the triangle in the figure, press the button to install
the wind wind, take it out in the direction of the arrow, clean the dust, rinse the filter
components and filter elements with water, and dry.
Cyclone cone limit slot
Air outlet HEPA detach buttom
