2.4.3. Sound Input Interface
SP-5B00 (Standard Box) does not have the sound input interface. It’s an
important note especially for those who use sound input with a microphone.
2.4.4. Sound Output Interface
If needed, apply SP5B10(Power box)’s AUX I/F.
The output value has been increased from 70mW to 300mW. Please take note of
it when you use an amplifier.
2.4.5. CF Card Interface
SP5000 series is not equipped with a CF card slot. But a SD card slot and a USB
interfaces are installed. In order to use the GP-3750T data saved in the CF card and
the functions using the CF card, use a SD card or a USB flash drive instead.
When the setting of the output destination folder is set to “CF Card” on GP-Pro EX,
if you change the display unit type, the setting will automatically change to the
one that uses a SD card.
To change the setting of the output destination folder, see [5.1 Changing the
setting of the external media to use].
