*1: RI and VICC of Pin 9 are switched on the software.
VCC Output is not protected from overcurrent.
Please follow the current rating to avoid false operation or breakdown.
4.3. Cable Diagram at the time of replacement
◆GP-3750T’s COM1 cable
For RS-232C connection, it can be used for the COM1 on SP-5B00(Standard Box)
as it is.
When a RS-422/485 device is connected via the COM1 port, if GP-3750T is
replaced with SP-5B00(Standard box), it will be connected via the COM2 port of
SP-5B00(Standard box). (The cable diagram can be still used.)
Before SP-5B00(Standard box) is connected, be sure to change the port setting to
COM2 on the Device/PLC setting.
Also, please check the communication settings with GP-Pro EX Device/PLC
Connection Manual just in case.
(http://www.pro-face.com/otasuke/files/manual/gpproex/new/device/index.ht
m)
◆GP-3750T’s COM2 cable
For the following case only, it can be used for the COM2 on SP-5B00(Standard
box) if the ”COM Port Conversion Adapter (CA3-ADPCOM-01)” is added to the GP’s
side.
When an online adapter (CA4-ADPONL-01) is attached to the GP-3750T’s cable,
detach it.
・ RS-422 cable (CA3-CBL422-01)
・ 2-port adapter cable (CA3-MDCB11)+2-port adapter II (GP070-MD11)
・ Multi-link cable (CA3-CBLMLT-01(5m))
・ Connector terminal conversion adapter (CA3-ADPTRM-01)+RS-422 cable
(homemade cable)
・ MPI cable (GP3000-MPI21-PFE)
・ SIEMENS COM port conversion adapter
(CA3-ADPSEI-01)+CA3-MPI-PGN-PFE or CA3-MPI-PG1-PFE
In all other cases, the operation is not guaranteed and it's recommended to
prepare a new connection cable. To check the cable diagram, please refer to
GP-Pro EX Device/PLC Connection Manual.
(http://www.pro-face.com/otasuke/files/manual/gpproex/new/device/index.htm)
4.4. Multilink Connection
For the communication drivers that support serial multi-link, see [Which drivers
support serial multilink communication?]
(http://www.pro-face.com/otasuke/files/manual/gpproex/new/device/com_mlnk.htm).
