pro master XC-M - Page 15

Center Column Upper Section
Center Column Lower Section
Center Column Lower Lock
Center Column Upper Lock
Center Column Platform
Ball Head
(also see figure6)
Panning
Knob
QR Plate
Tension
Knob
Memory
Lock
Leg Angle Switch
(3 in total)
Yoke
Leg Locks
Center
Column
Weight Hook
(also see figure 4)
Tool Kit
(also see figure 3)
Double-Sided Platform Screw
(connects Ball Head to
Center Column Platform)
QR Knob
Removable
Feet
Bullseye
Level
PARTS DIAGRAM
