Pro-Max CG14SPT - Page 11

11
STAR MANUFACTURING INTERNATIONAL, INC.
SK2336 REV. A 6/30/11
MODEL: GR14SPTIP240
CERTAIN INSTANCES MAY NOT BE AVAILABLE
ILLUSTRATIVE PURPOSES ONLY AND IN
SOME ITEMS ARE INCLUDED FOR
48
62
10
B
A
C
D
SENSOR - RIGHT
(SENSORIO)
BOTTOM ELEMENT
(ELEMENTO MAS BAJO)
TOP ELEMENT
RIGHT
(ELEMENT MAS ALTO)
GREEN
BLACK
WHITE
1
3
2
3
4
1
2
4
7
7
8
14
15
13
16
SENSOR - LEFT
(SENSORIO)
TOP ELEMENT
LEFT
(ELEMENT MAS ALTO)
TRANSFORMER
(TRANSFORMADOR)
RELAY
(RELE)
TERMINAL BLOCK
(BLOQUE TERMINAL)
FOR REFERENCE
WIRING DIAGRAM IS SHOWN AS UNIT IS ASSEMBLED
WITH THE BOTTOM PLATE REMOVED. THE TOP
DESCRIPTIONS ARE THEIR POSITIONS WHEN UPRIGHT.
1
0
8
4
62
SWITCH
(INTERRUPTOR)
5
6
120V UNITS PLUG
NEMA 5-20P 2,300 WATTS
NEMA 5-30P 2,300 WATTS
240V UNITS PLUG
NEMA 6-15P 2,300 WATTS
NEMA 6-20P 3,550 WATTS
8
17
17
15
16
13
14
6
5
REAR OF CONTROLLER
E1
E4
E2
E11
E12
E3
E7
E6
E5
WIRE DIAGRAM
