Pro-Max CG14SPT - Parts List

14
&*637&*637,*9&99&**567(
*5637$*5637&*5637.9&99
&**5637,9*5637,36SOLW/LG7DEOH7RS*ULOO
PARTS LIST November 23, 2011, Rev N
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED   3$*( 
INCLUDE MODEL AND SERIAL NUMBER OF 4
Some items are included for illustrative purposes only and in certain instances may not be available.
MODEL
Star International Holdings, Inc. Company
2M-Z5818, Split-Top Two Sided Grill
Item
No
Part No Qty Description Application
1 2M-Z2620 2 LABEL CAUTION, BI-LINGUAL
2 2C-Z3200 4 PIN - TOP HOUSING
3 2A-Z3827 2 PLATE, STAMPING CONDUIT
4
D9-GR0181 2 TOP HOUSING & CONDUIT ASSEMBLY
D9-Z11716
1
TOP HOUSING, LT SPLT
CG14STKE-120, GR14STB, GR14STE,
GR14STKE120C
D9-Z11717 TOP HOUSING, RT SPLT
5 2C-Z5883 8 10-24 X 1/2” FZA SCREW, TOP HOUSING
6 B9-04-WB-0046 2 CLAMP WIRE SUPPORT
7 D9-GR0182 2 TOP RETAINING PLATE ASSEMBLY
8 D9-Z2133 2 INSULATION FIBERGLASS TOP
9
2A-Z6604
12 SPACER - INSULATION PLATE
2A-Z9514 SPTC, SPTI
10
D9-Z3902
2 PLATE - TOP ELEMENT RETAINING
D9-Z9513 SPTC, SPTI
11
PS-Z9325
2
ELEMENT, HEATING, TOP 500W 120V
PS-Z9326 ELEMENT, HEATING, TOP 500W 230/240V SPT, SPTA, SPTC, SPTA, SPTG 230/240V
PS-Z9521 ELEMENT, HEATING, TOP 700W SPTI
2N-Z13966 ELEMENT, 400W 120V SPT CG14STE120CL
2N-Z11709 ELEMENT, 650 WATT, 120V CG14STKE, GR14STE, GR14STKE
2N-Z14893 ELEMENT, 650W, 208V TOP STE GR14STECB208
12 2C-Z3350 2 HALF CLAMP - .188 DIAMETER
13 D9-Z3903 2 BRACKET, PROBE MOUNT
14 2E-Z3278 2
RTD PROBE - 48” LONG WIRE -
THERMISTOR
15
PS-GR0356
2
KIT, 2F-Z3237 CASTING REPLACMENT SMOOTH - ALUM
PS-GR0355 KIT, 2F-Z5615 CASTING REPLACMENT GROOVED - ALUM
PS-GR0504 KIT, 2F-Z5615 COATED CASTING REP. GROOVED - ALUM
2F-Z9651 CASTING - TOP SMOOTH, CHROME
2F-Z8349 CASTING - TOP SMOOTH, IRON
2F-Z7967 CASTING - TOP GROOVE, IRON
16 2V-Z3152 2 HANDLE
17
2B-Z3336
4
14” CG14SPT ARM
2B-Z9515 ARM SPTC, SPTI
2B-Z10355 ARM CG14SPTK-120/240V, GR14SPTKM-UK
2B-Z12554
2
ARM, LEFT ST
CG14STKE-120, GR14STB, GR14STE,
GR14STKE120C
2B-Z12555 ARM, RIGHT ST
CG14STKE-120, GR14STB, GR14STE,
GR14STKE120C
18 2C-08-07-0040 12 ACORN NUT, 1/4-20 ACHD STL NP
19 2C-08-07-0262 8 WASHER 1/4 INT STL NP
20
2C-Z2992 12 BOLT 1/4-20X1 PHP STL NP Used w/Fig. No 28
2C-1523
4
.250-20UNC X 0.75 LG RHP SCREW
Used w/Fig. No 28.12C-08-07-0262 .250 INTERNAL TOOTH LOCK WASHER
ADD LOCKTITE 242 TO THREADS
