Pro-Max CG14SPT - Page 15

15
PARTS LIST November 23, 2011, Rev N
&*637&*637,*9&99
*5637$*5637&*5637.9&99
&**5637,9*5637,36SOLW/LG7DEOH7RS*ULOO
MODEL
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED   3$*( 
INCLUDE MODEL AND SERIAL NUMBER OF 4
Some items are included for illustrative purposes only and in certain instances may not be available.
Star International Holdings, Inc. Company
2M-Z5818, Split-Top Two Sided Grill
Item
No
Part No Qty Description Application
21 2C-Z3917 4 RIVET, POP,
22 2E-Z2898 2 CONDUIT ASSEMBLY
23 2E-Z3768 2 LOCKNUT, CONDUIT 1/2”
24 2C-Z3780 4 RETAINER, CONDUIT
25 2V-Z3252 2 TOP HOUSING LATCH ROD
26 2A-Y6142 4 SLEEVE HANDLE
27 2C-1516 4 SCREW 10-24 X 1” STL RH NP, LATCH ROD
28 2R-Z3345 1 COUNTER BALANCE - SPLIT TOP
28.1 PS-GR0536 2 KIT, HINGE & SPRING, 14SPLT
CG14STE, CG14STKE, GR14STB,
GR14STE,GR14STKE120C
29 2C-Z2593 4 SCREW - 10-24X1 1/2 SL HX/W NP
30 D9-Z11677 1 INSULATION BAFFLE ASSEMBLY
31 D9-Z3826 1 INSULATION - BAFFLE
32 2A-Z6484 2 PLATE (COUNTER BALANCE MOUNT)
33
D9-GR0152
1
BODY ASSEMBLYD9-GR0393 CG14SPTK-120/240V
D9-GR0394 GR14SPTIP
D9-GR0507 BODY ASSY - 14” CG/CG14 GR14STE
D9-GR0461 BODY ASSY 14” SPT GR14STB
34
2M-Z5817
1
OVERLAY-STANDARD
CG14SPT, CG14SPTI, CG14STE, GR14SPTA,
GR14SPTC, GR14SPTI, GR14SPB,. GR14STE
2M-Z3337
OVERLAY
GR14SPT-120/240V & CUL
2M-Z10851 CG14SPTK-120/240V
2M-Z11984 GR14STE-120
2M-Z11983 GR14STE-120V
2M-Z10087 2 GR14STKE120C, GR14SPTK-120, GR14SPTKM
35 Z1-70-07-0343 1 SWITCH GUARD
36 2M-12-07-0038 1 LABEL ON & OFF
37 2I-05-07-0013 1 BOOT SWITCH
38
D9-GR0518
1 GREASE DRAWER ASSEMBLY
CG14SPTK, CG14STE
D9-GR0517 GR14SPTKG120, GR14STKE, GR14SPTKM
39 2E-Z3808 1 SWITCH TOGGLE
40
2J-Z6323
1
TIME/TEMPERATURE CONTROL
2J-Z13327 GR14STECB208
D9-GR0387 CONTROL PROGRAMMING CG14SPTK-120/120C/240V
D9-GR0380 CONTROL PROGRAMMING GR14SPTK-120/120C, GR14SPTKM120
D9-GR0539 CONTROL PROGRAMMING GR14SPTKM-UK
41 2K-Z1971 14 SPACER
42
D9-GR0151
1
FACEPLATE ASSEMBLY
D9-GR0382 FACEPLATE ASSEMBLY CG14SPTK
43 2E-Z3335
2
RELAY DOUBLE POLE-SINGLE THROW
3 GR14STECB208
44
2E-05-07-0350
1
TRANSFORMER 230V/10V 6VA 230V
2E-05-07-0351 TRANSFORMER 115/10V 6VA
