pro.point 8662280 - Parts List

8662280 1,000 LB HYDRAULIC RAPIDLIFT TABLE CART V1.0
12 For technical questions call 1-800-665-8685
PARTS LIST
# DESCRIPTION QTY
1
PROTECTIVE MAT
1
2
TABLE
1
3
SCISSOR ARM (UPPER)
1
4
ROLLER (UPPER)
2
5
RETAINING RING 12
6
6
PIN
2
7
LOCK NUT M16
4
8
WASHER 16
4
9
AXLE
2
10
BOTTOM SCISSOR ARM (OUTER)
1
11
SCREW M8x12
1
12
BOTTOM SCISSOR ARM (INNER)
1
13
BASE
1
14
AXLE
1
15
RETAINING RING 25
2
16
LOCK NUT M12
2
17
WHEEL 5 IN.
2
18
BUSHER
2
19
HEX BOLT M12x85
2
20
POWER UNIT
1
21
HEX NUT M8
12
22
RELEASE VALVE LINK
1
23
WASHER 8
8
24
BOLT M8x25
1
25
PIN 8x40
1
26
COTTER PIN 2.5x24
3
27
SCREW M8x20
1
28
LINKAGE
2
29
PIN 10x28
1
30
SPRING
1
31
SPRING CAP
1
