pro.point 8667784 - Parts List

V1.2 1,000 LB HYDRAULIC/PNEUMATIC MOTORCYCLE LIFT 8667784
Visit www.princessauto.com for more information 15
PARTS LIST
#
DESCRIPTION
QTY
1
Bolt M10×25
8
2
Front Arm Support
1
3
Washer Ø12
16
4
Washer Ø10
2
5
Spring Washer Ø10
2
6 Nut M10 2
7
Support
2
8
Adjusting Screw
2
9
Washer Ø6
2
10
Nut M6
2
11
Universal Wheel
2
12
Washer Ø8
4
13
Bolt M8×18
1
14
Release Valve Spindle
1
15
Release Foot Pedal
1
16
Pump Foot Pedal
Spindle
1
17
Pump Seat
2
18
pump Foot Pedal
1
19
Spring
1
20
Pump Connecting
Rod
1
21
Pin
8
22
Retainer Ring Ø12
16
23
Wheel
2
24
Washer Ø14
2
25
Retainer Ring Ø14
2
26
Washer Ø10
8
27
Spring Washer Ø10
8
28
Frame assembly
1
29
Nut M10
6
30
Bolt M8X30
4
31
Release Connecting
Rod
1
32
Nut M8
4
33
Rear Arm Support
1
34
Shaft
1
35
Washer Ø20
2
36
Retainer Ring Ø20
2
37
Bolt M10×10
1
38
Pump Head
Component
1
39
Pump
1
40
Ramp
1
41
Moveable Plate
1
42
Platform
1
43
Elastic Cylindrical Pin
1
44
Safety Bar
1
45
Spring Washer Ø8
1
46
Spindle
1
47
Bolt M8X20
12
48
Washer Ø8
6
49
Track
2
50
Bolt M10X20
2
51
Spring Washer Ø10
2
52
Washer Ø10
1
53
Rubber Plug
1
54
Dam-board
1
55
Clamp Frame
1
56
Movable Frame
1
57
R-pin
1
58
Ring
1
