1. Saw arm
2. Release knob
3. Operating handle
4. Carrying handle
5. Upper fixed blade guard
6. Clamp assembly
7. Clamp assembly lock (x2)
8. Rotating blade guard
9. Guard retraction arm
10. Blade bolt cover
11. Dust bag
12. Bevel lock
13. Bevel scale
14. Fence
15. 6mm Hex key
16. Mitre table
17. Mitre scale
18. Table insert (kerf plate)
19. Switch trigger
20. Mitre lock
21. Spindle lock
22. Dust extraction port
23. Slide bars
24. Slide lock
25. Trenching depth adjustment screw
26. Trenching stop
27. Trenching depth lock nut
28. 45° Bevel adjustment screw (left)
29. Side support bars (x2)
30. Side support bar location holes (2 sets)
31. Side support bar locking screws
32. Stabiliser bar
Parts list
KNOW YOUR PRODUCT KNOW YOUR PRODUCT
11
15
28
31
29
30
3
5
6
7
8
9
10
13
14
16
17
18
19
20
25
26
27
32
1
2
4
12
22
23
24
21
