PRO-PULSE PAK152c - Parts List

12
PAK152c
ENGLISH
N
O.
DESCRIPTION QTY..
1 Air Receiver 1
2 Crankcase 1
3 Oil sight glass 1
4 Shaft seal 1
5 Oil breather cap 1
6 Gasket 1
7 Connecting rod 1
8 Circlips 2
9 Piston ring set 1
10 Piston 1
11 Piston oil ring 2
12 Compression ring 1
13 Cylinder 1
14 Washer 4
15 Bolt 4
16 Gasket 1
17 Valve assembly 2
18 Valve plate 2
19 Valve plate spacer 1
20 Gasket 1
21 Cylinder head 1
22 Head bolt 4
23 Spring washer 4
24 Air lter kit 1
25 Exhaust pipe 1
26 Crankshaft 1
27 Screw nut 1
28 Head Bolt 1
29 Handle 1
30 Shaft seal 1
31 Bearing 1
32 Rotor 1
33 Stator 1
34 Bearing 1
N
O.
DESCRIPTION QTY..
35 Rear cap 1
36 Capacitor 1
37 Capacitor 1
38 Screw nut 2
39 Washer 3
40 Spring washer 3
41 Head bolt 3
42 Circuit board 1
43 Circuit breaker 1
44 Head bolt 2
45 Fan 1
46 Cover 1
47 Head bolt 10
48 Pressure gauge 1
49 Connector 1
50 Safety valve 1
51 Regulator 1
52 Air valve 1
53 Pressure gauge 1
54 Pressure gauge 1
55 Cushion foot 4
56 Head bolt 4
57 Screw nut 4
58 Washer 4
59 Unloader tube 1
60 Check valve 1
61 Exhaust pipe 1
62 Exhaust pipe 1
63 Drain cock 1
64 Screw nut 2
65 Crankcase cover gasket 1
66 Crankcase cover 1
67 Head bolt 4
68 Spring washer 4
PARTS LIST
Please refer to the Schematic Drawing on the preceding pages.
NOTE: Due to continuous product improvement, we reserve the right to change
product specications without prior notice.
