INTRODUCTION
The Mini LAN cable tester complies with CE safety standard, compact size and
lightweight design for easy detection of good connections, opens, crossed wires &
split pairs by only one touch testing. Trace wires with tone, easy and fast. Remote
lights allow one person operation. Additional non-contact voltage detection provides
user safety. Ideal for testing installed cables or patch cords with RJ-45, RJ-11, RJ12
and BNC connectors.
SAFETY RULES& WARNINGS
Warning
The tester is not intended for use on powered circuits. Attaching this
tester to a powered circuit can result in damage to the tester or injury
to the user.
1. Read all instruction in this manual before using this tester. Failure to do so may
result in damage to the tester or injury to the user.
2. Do not use this tester when its case open, or when parts removed. Doing so may
damage the tester and/or injure the user.
3. When using this tester in schools and workshops, responsible teachers or skilled
personnel must control the usage of this tester. Failure to observe this precaution
may result in damage to the tester or injury to the user.
4. Follow the recommendations of any Trade Organizations or Regulatory Agencies
whose scope encompasses the use of this tester failure to do so may result in
damage to the tester or injury to the user.
5. Repairs and maintenance must only be carried out by qualified service personnel
or qualified electricians/technicians who know the dangers of.
6. Do not apply voltage or current to any of the tester’s connectors. Doing so may
damage the tester and /or injury the user.
7. Remove the battery when the tester not in use for longer than a month. Chemical
leakage from the battery could damage the tester.
PRODUCT FEATURES
1. Complies with CE safety standard
2. Automatically detect good connections, opens, crossed wires & split pairs.
3. Multiple mode measurement options.
4. Simple one button test
5. LEDs indicate connections and faults
6. Tests shielded (STP)or unshielded(UTP) LAN cables
7. BNC cable indicator
8. Non-contact voltage detection for user safety.
9. Long cable test more than 300 meters
10. Low power consumption with auto power off function to preserve battery.
SPECIFICATIONS
1. Cables Tested: UTP and STP LAN cables Terminated in RJ-45 male connectors.
(EIA/ TIA 568)RJ-11, RJ-12 cables with male connectors, 2 to 6 connectors
installed. BNC cables with male connectors.
2. Faults Indicated: No Connection, Short, Straight, and Crossover.
3. Low Battery Indicator: LED lights red colors to indicate low battery
