Pro's Pro challenger I - Description of Parts; Assembly Instruction

PRO’S PRO
®
CHALLENGER I
Seite 2 von 5
PRO’ S PRO
®
—CHALLENGER
•Description of Parts
1. Assembly Instruction
Step 1: After opening the box, remove the installation and operation manual.
The angled support (8), The string clamp (9), Four L-Shaped wrenches, Long
nose pliers(17) and diagonal cutting pliers. Remove the foam box, Remove the
machine from the foam box .
Step 3: Rotate the mounting table and lift the tension bar.
1) Machine Base
2) Liner String Gripper
3) Tension Bar Drum
4) Ratchet System with clutch
5) Latch
6) Drop Weight Knob
7) Drop Weight
8) Tension Bar
9) Tension Bar End Cap
10) Side support arm
11) Angled Support
12) String Clamp
13) Frame Support
14) Mounting Table
15) Swivel Base
16) 3.0 m/m l-shaped wrench
17) 4.0 m/m l-shaped wrench
18) 5.0 m/m l-shaped wrench
19) 6.0 m/m l-shaped wrench
20) Long Nose Pliers
21) Diagonal Cutting Pliers
9
7
6
8 3
4
5
2
1
15
14
13
12
11
10
16
17
18
19
20 21
