Pro'sKit MT-1236 - Precision Specifications; DC Voltage Measurement Accuracy

or AC (valid value)
 Protection of protective tube: mA position: protective tube F 600mA/250V; A
position protective tube F 10A/250V
 Rotation rate: approximately 3 revolutions/second
 Display unit: 6000 counts displayed on LCD screen. Automatically display the
symbol for unit in accordance with measurement function position.
 Outrange indication: the LCD screen will display "OL".
 Battery Low indication: “ ” will appear when the battery's voltage is below
the normal working voltage.
 Input polarity indication: “” will automatically appear.
 Power: 3 x 1.5V AAA battery
 Dimensions: 148mm(L)×79mm(W)×48mm(H).
 Weight: approximately 210g (not included batteries or test leads)
4.2 Precision indicator
Accuracy: ( reading + digit)
The accuracy warranty will run for 1 year upon the ex-factory date.
Reference conditions: ambient temperature is between 18℃ and 28℃ and relative
humidity is no more than 80.
4.2.1 DC voltage
Measuring range
Resolution
Accuracy
600mV
0.1mV
±(0.5%Reading+5digits)
6V
1mV
60V
10mV
600V
1V
Input impedance:10M
Maximal input voltage: 600V DC or AC valid value
4.2.2 AC voltage
Measuring range
Resolution
Accuracy
600mV
0.1mV
±（1% readings +4 digits）
6.000V
0.001V
60.00V
0.01V
600V
0.1V
Input impedance:10M
Maximal input voltage: 600V DC or AC valid value
Frequency response: 40Hz-1kHz True-Rms
