Technical Parameters Cont.
Part Name(English) Part No. Qty.
Display overlay 1600549 1
Control box top 1200446 1
Circuit breaker 15A 1800160 1
On/off switch 1800346 1
Emergency stop button 1200579 1
socket 1800344 1
Triac 1800586 1
Cooing sheet 1300672 1
Terminal Block 1800345 1
Circuit Board 1800353 1
Magnet switch 1800620 1
Magent 1800609 1
Control box base 1200685 1
16 5 phase aviation plug
(Female) with wires
welded
1800955 1
17 2 phase aviation plug
!Female"#with wires
welded
1800962 1
18 Machine handle 1200581 2
Machine handle 1200395 2
19 Machine arm 1200583 2
Machine arm 1200409 2
20 Washer 20-13-15 2000296 2
21 Lift links 1200140 2
Lift links 1200139 2
23 Machine body 1200582 2
Machine body 1200397 2
24 Supporting block 1200043 3
25 Rubber foot 1800317 4
