ProBoat Jet Jam PRB08031 - Box Contents; Recommended Tools and Materials; Placing the Decals; Installing the Battery Pack

Installing the Battery Pack
Placing the Decals
4
EN
Jet Jam
Recommended Tools and Materials
• Needle nose pliers
• Paper towel
• Rubbing alcohol
• Phillips screwdriver: #1, #2
• Hex drivers: 1.5mm and 2mm
• Clear tape (DYNM0102)
• ProBoat
®
Marine Grease and Gun (DYNE4200)
1. Remove the canopy from the hull by rotating the
canopy latch to the left or right and pulling up on
the back of the canopy.
2. Install the fully charged battery in the compartment
by securing it into the battery cradle with the battery
cable toward the front of the boat.
3. Connect the battery to the ESC/Receiver.
Box Contents
• ProBoat
®
Jet Jam™ 12-Inch RTR Pool Racer
• ProBoat
®
2.4GHz Transmitter (PRB18020)
• ProBoat
®
ESC/Receiver (PRB18017)
• ProBoat
®
Servo (PRB18018)
• Dynamite
®
7.4 1500 mAh 2S 15C Li-Ion Battery (DYNB0110)
ON
OFF
1
1
2
2
3
3
4
4
5
5
7
7
6
6
