Simple Start Up Procedure:
Ÿ Start computer
Ÿ Launch LinuxCNC from icon on desktop
Ÿ Turn power on Unity Controller
Ÿ Verify red E-Stop indicator follows physical e-stop
Ÿ Click orange Machine Power button
Ÿ Click the Home All button
Ÿ Click folder icon to open g-code file
Ÿ Load tool into spindle or router
Ÿ Mount stock on the table
Ÿ Jog machine to place tool on origin of part
Ÿ Perform touch-off sequence (all 3 axis)
Ÿ Verify spindle power switch is on
Ÿ Hit the Run button
Ÿ Watch in awe
*There are additional instruction in the wiki for using the Z
Touch-off puck and the ATLaS Automatic Tool Length
Sensor.
