PUMP – GROUP PARTS LIST
COMANCHE 86038910 08/28/13
5-6
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86233150 20042 6 CLAMP, 3/8 HOSE (D-SLOT)
2 86280970 39233 1 HOSE, 3/8 RUBBER X 17"
3 86281500 39403 1 HOSE, 3/8 RUBBER X 5"
4 86161630 12-800398 1 HOSEBARB, "Y" 3/8 ALL NYLON
5 86281050 39250 1 HOSE, 3/8 RUBBER X 12"
6 86001550 40043 1 HOSEBARB, 3/8 MPT X 3/8 90D
7 86251120 65220 1 FLOJET 100 PSI PUMP 220V 1000107206
8 86197440 31056 1 ELBOW, 3/8 MPT X 1/4 FPT
9 86010650 87018 4 WASHER, #10 X 9/16 OD
10 86270990 57090 6 NUT, 10-32 HEX NYLOCK SS
11 86005580 56012 1 NIPPLE, 1/4 FPT QD
12 86202230 390-09A 1 WASHER 9/16 S/S USS-THICK
13 86161660 39599 1 HOSE, HP 23.0 1/4 MPT X 1/4 MPT
14 86276240 70614 2 SCR, 10-32 X 1 1/8 PPHMS SS
15 86161640 39597 1 HOSE, HP 15.0 1/4 MPT X 1/4 MPT
16 86197350 22014 1 COUPLER, 1/4 F HEX
17 86005700 57104 4 NUT, 10-32 W/STAR WASHER PLTD
18 86072720 14454 1 BRKT, VALVE
19 86246850 54182 1 MANIFOLD, ASM
20 86042430 62964 1 PLATE, CM MANIFOLD
21 86272730 66017 2 PLUG, 1/4 BRASS PIPE
22 86275810 70547 6 SCR, 10-32 X 1 PPHMS BLK
23 86256180 73195 1 STRAIN RELIEF, 1/2 NPT (.48ID)
24 86162280 64-950582 1 CORD, MOLD ENGLAND 220V 25’
25 86005670 57040 1 NUT, 1/2 NPT CONDUIT
26 86279530 87173 1 WASHER, .765 ID X 1.31 OD X .09T SS
27 86162060 84197 1 VALVE, BPR 125 PSI, BRASS
28 86070220 140587 1 BRKT, VALVE SFTY
