PREPARATION
Tools Required
• Phillips Screwdriver
• Wire Cutter
This blower contains assembly instructions for ED series.
For the CRHQD250T, CRHSD25RT, BD23 series, Q stove, PCSD25RT series and FBD400
series see page 8 - 13.
BLOWER INSTALLATION ED SERIES
Install
Rocker
Switch
Install
Blower
Top Cover
Install Power
Cord and
Grounding
Terminal
Protection Tab
Install Temperature
Sensor to Back
of Firebox after
Removing Top Cover
