18/32
2009/10 - Indice de révision : I - Code : 0035001
SAFETY AND INSTALLATION PRESCRIPTIONS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 20
PREPARATION BEFORE INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 21
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 21
MOTORISED VERSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 23
FINISH
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 24
USE
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 26
SAFETY VOLUMES STIPULATED IN THE FRENCH STANDARD C15-100
. . . . . . . . . . . . . . . . .
Page 27
MANUAL VERSION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 28
ASSEMBLY OF THE CRANK WHEEL
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 28
ASSEMBLY OF THE BEARING AND REDUCTION GEAR
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 29
ASSEMBLY OF THE AXLE
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 31
USE
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 31
UPKEEP AND WINTERIZING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 31
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 32
TABLE OF CONTENTS
Equipment supplied
Aquadeck ES
1 Motorised axle
1 Aquadeck E flange and casing assembly
1 Aquadeck ES flange and casing assembly
1 Battery,12V-12Ah for Aquadeck EB and ES
1 Aquadeck ES cover control pad
2 Button head screws 4x12 PA 6.6 DIN84A
2 Pozidriv button head screws 4.8x22 A4 DIN7981C
4 Hex head screws 6x50 A4 DIN933
4 Hex head screws 8x35 A4 DIN933
4 Express studs D10x124 A4
8 Hex collar nuts M8 A4 DIN6923
12 Washer Z 8 A4 NFE25513
1 Delta cover floating key chain
Aquadeck EB
1 Motorised axle
1 Aquadeck E flange and casing assembly
1 Aquadeck EB and EC flange and casing assembly
1 Aquadeck EB cover control pad
1 Battery, 12V-12Ah for Aquadeck EB and ES
1 Battery charger 12V/1A IP67/ Aquadeck EB
2 Button head screws 4x12 PA 6.6 DIN84A
2 Pozidriv button head screws 4.8x22 A4 DIN7981C
4 Hex head screws 6x50 A4 DIN933
4 Hex head screws 8x35 A4 DIN933
4 Express stud D10x124 A4
8 Hex collar nuts M8 A4 DIN6923
12 Washer Z 8 A4 NFE25513
1 Delta cover floating key chain
Aquadeck EC
1 Motorised axle
1 Aquadeck E flange and casing assembly
1 Aquadeck EB and EC flange and casing assembly
1 Aquadeck EC cover control pad
1 Aquadeck EC cover control panel
2 Button head screws 4x12 PA 6.6 DIN84A
2 Pozidriv button head screws 4.8x22 A4 DIN7981C
4 Hex head screws 6x50 A4 DIN933
4 Hex head screws 8x35 A4 DIN933
4 Express studs D10x124 A4
8 Hex collar nuts A4 DIN6923
12 Washer Z 8 A4 NFE25513
1 Oval plug 50x30 for Aquadeck EB flange
1 Delta cover floating key chain
Aquadeck EM
1 Hand operated axle
1 Aquadeck E flange and casing assembly
1 Aquadeck EM flange and casing assembly
1 Reduction gear for Aquadeck EM mechanical assembly
2 Reduction gear flanges for Aquadeck EM
1 Flywheel kit
1 Sleeve for the Aquadeck EM flywheel stem
2 HSHC screws 6x16 A4 DIN912
2 Screws CS 4x12 PA 6.6 DIN84A
4 HSHC screws 8x35 A4 DIN912
4 Hex head screws 6x50 A4 DIN933
4 Hex head screws 8x35 A4 DIN933
4 Hex collar nuts A4 DIN6923
4 Express studs D10x124 A4
12 Washer Z 8 A4 NFE25513
