8
Diagrama de Compresor de Aire
HCOM001-2HD-FOG
(Sistemas grandes)
# PART NUMBER DESCRIPTION QTTY
1 1COM005-C Air Comp. Single Head 110 VAC 1
2
3
2PMCQ38M14 Male Con, 3/8 inch QC x 1/4 inch MPT 1
2AFIL-INL14-5MIC Air Filter 1/4 inch FNPT 5 mic 1
4
5
2FCVAL-M14 Air Flow Control Valve 1/4 inch NPT 1
6
2GAU010 Gauge 1.5 inch, 1/4 NPT, 0-60 1
7
1WIR050 Wire, 16/3 Extension Cord 1
2AFIL003 Air Intake Filter 1/4 inch NPT 1
4
32
1
5
7
6
To Next Page
