INTRODUCTION
ThankyouforchoosingthisPROELproductandforyourtrustinourbrand,synonymousofprofessionalism,
accuracy, high quality and reliability. All our products are CE approved and designed for continuous use in
professionalsystems.
DESCRIPTION
TheWM202WirelessMicrophonesseriesisaUHF,quartzcontrolled,fixedfrequencydevice,whichprovides
areliable,highqualitysignaltransmission.
WM202 Wireless Microphone system features 3 units: WM202 receiver, WM2M handheld transmitter and
WM2H body pack transmitter. The system is available in threedifferent configurations, each of them
includinganABSca
rryingcase:
WM202M: WM202+WM2M
WM202H: WM202+WM2H+lavalier+headset
WM202KIT: WM202+WM2M+WM2H+lavalier+headset
Four factory pre‐build frequencies are available, which have been accurately selected to allow the
simultaneoususeof4deviceswithoutinterferencebe
tweenthem:
1. 863.100MHz
2. 863.900MHz
3. 864.500MHz
4. 864.900MHz
WM202RECEIVER
SeeFIG.1atpage15:
1. DCIN
SocketfortheAC/DCadaptorconnection,useonlytheadaptorsuppliedwiththesystem.
2. OU TPUT(UNBAL ANCED)
Unbalancedaudiooutputwithlinelevel:connectitthroughamono6.3mmjackcabletoamixerinput.
3. OU TPUT(BALANCED)
Balancedaudiooutputwithmi
clevel:connectitthroughaXLRcabletoamixerinput.
4. POWER
On/offswitch.
5. ON
RedLED: iflightedstatesthatthepowersupplyispresentandthereceiveristurnedon.
6. RF
GreenLED:iflightedstatesthatthetransmitterissendingaradiosignaltoth
ereceiver.
7. AF
RedLED: illuminateswhenanaudiosignalispresent.
8. VOLUME
Volumepotentiometer:setthiscontroltoaproperlevelthatdoesn’tsaturatethemixerinputchannel.
9. ANTENNA
Thesearethereceivingantennas.Raisethemupduringtheuseand,toobtainabetterreception,place
there
ceiverawayfromothermetalobjectsandnomoredistantthan30mfromthetransmitter.
10. RECEIVINGFREQUENCY
Inthislabel,togetherwiththegeneraldataofthereceiver,youcanfindthereceivingradiofrequency.
Incaseofuseofmoreradioapparatusitmustcorrespondtothef
requencyofthewirelesstransmitter
