MULTIMETRE MEDIUM EN - 3
PIN-116
Replacing the fusing
Warning! To prevent electric shocks you must
disconnect the testing wires from any power sources
before you open the cover of the fuse compartment.
1. Disconnect the testing wires from the metre and
all items to be tested.
2. Remove the rubber housing
3. Open the fusing compartment cover by removing
the screw in the cover.
4. Remove the old fusing from the compartment by
carefully pulling it out.
5. Place the new fusing in the holder.
6. Always use fusing of the correct size and
specification (10A/250V fast-reacting for the 10A
range).
7. Replace the fusing cover. Insert the screw and
tighten firmly.
Warning! To prevent electric shocks you may not
use the metre until the cover of the fuse
compartment has been replaced and fastened.
Specifications
Overvoltage category: CATII
Display: 2,000 counts
Polarity: Automatic, (-) indication negative polarity.
Various Graphics
DC voltage
Range Resolution Accuracy
200mV 0.1mV
2000mV 1mV
+/- 0,5% van rdg
+/- 2- figures
20V 0.01mV
200V 0.1mV
+/- 0,8% van rdg
+/- 2- figures
600V 1V +/- 1% van rdg
+/- 2- figures
AC voltage
Range Resolution Accuracy
200V 0.1V +/- 1,2% van rdg
+/- 10- figures
600V 1V 50/60Hz
Direct current
Range Resolution Accuracy
2000 μ 1 μA
20mA 10 μA
+/- 1% van rdg
+/- 2- figures
200mA 100 μA +/- 1.2% van rdg
+/- 2- figures
10A 10mA +/- 3.0% van rdg
+/- 2- figures
Resistance
Range Resolution Accuracy
200 Ω 0.1 Ω
2000 Ω 1 Ω
20k Ω 0.01k Ω
200k Ω 0.1 k Ω
+/- 0.8% van rdg
+/- 2- figures
2000k Ω 1 k Ω +/-1.2% van rdg
+/- 2- figures
Temperature
Range Resolution
-20°C ~+760°C 1°C
-4°F ~1400°F 1°F
Diodetest
Test current
Max 1mA
Open circuit voltage: 2.8 V DC typical
