Phone jack must be connected to the H10 connector that is placed in the board behind the keyboard.
Look at the following picture.
6. Cables disconnected in point 3 must be connected back again. Place the keyboard in the box and
move the new installed cable to the upper side of the box, avoiding it to directly pass over the
main board and the keyboard.
7. Close the equipment by screwing the screws removed in point 2.
8. Connect Agrónic 2500 with PC by means of the new USB cable provided.
9. Switch on the equipment and activate (if necessary) the “Agrónic PC Program” option in “Parameters
– Installer”.
10. Setup the suitable configuration according to the “Agrónic 2500 Communications Supplement” user
manual.
R-1933
