Progrés Agronic 4500 Replacing Manual

RECESSED FORMAT ASSEMBLY
Manual - Agrónic 4500 · 3
Disconnect power from the
Agrónic 4000.
1
Remove the six side screws
and two central screws.
2
Separate the keyboard from
the box.
3
Check whether the unit
has any telephone type cables
connected to the keyboard. If it
does, disconnect them from the
plate because they are unusable.
4
Agrónic 4500 front panel for recessed model:
- Agrónic 4500 micro plate
- Agrónic 4500 keyboard
- Integrated GPRS/4G or WiFi modem -
Integrated eSIM card -
Antenna
Replacing the front of the Agrónic
4000 to Agrónic 4500 for recessed
model
Agrónic 4500
Agrónic 4500 frontal recessed model
SUPPLIED MATERIAL
If the Agrónic 4500 unit has
an analog I/O option, remove the
option by removing the three screws,
so that the front can be changed.
6
If the Agrónic 4000 unit has a
GPRS modem option, remove the
modem, the antenna and also the
power cable that is connected to
the relay or analog I/O board. (The
Agrónic 4500 is supplied fitted with
its modem and integrated eSIM
card).
5

Progrés Agronic 4500 Specifications

General

Brand	Progrés
Model	Agronic 4500
Category	Control Unit
Language	English
