Progressive Dynamics PD52 Series User Manual

Consult a licensed electrician or RV technician for installation assistance
Specifications
(Specifications subject to change without notice)
Model
PD52_ PD52DCS_ PD53
Voltage Rating
Current Rating (line)
Current Rating (neutral)
Dominant Source
Open Neutral Protection
Reverse Polarity Protection
Safety Interlocks
Under Voltage Protection
Over Voltage Protection
Multimode Surge Protection
Surge Energy Rating
Surge Current Rating
Weight
Dimensions
Listed
120/240Vac
50A
70A
Generator
No
No
Mechanical & Electrical
No
No
No
n/a
n/a
7 lbs
10.38L x 6.88W x 4.50H
Yes
120/240Vac
50A
70A
Generator
Yes
Yes
Mechanical & Electrical
Yes
Yes
Yes
3,300 Joules
103,000A
10 lbs
10.25L x 8.25W x 5.50H
Yes
120/240Vac
100A
100A
Generator
No
No
Mechanical & Electrical
No
No
No
n/a
n/a
17 lbs
12.00L x 10.00W x 6.00H
No
TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSES
ACTION
No Output when
Plugged into Shore
Power
Wiring error between shore power and the transfer
switch.
Correct wiring
Defective transfer switch
Replace transfer switch
Wiring error between generator and the transfer
switch
Correct wiring
Generator malfunction
Have generator serviced
No Output when
Generator is Running
Wiring error between generator and the transfer
switch.
Correct wiring
Generator malfunction
Have generator serviced
Defective transfer switch
Replace transfer switch
No Output to Auto
Generator Start
Wiring error between shore power and the transfer
switch.
Correct wiring
Bad voltage sense control board.
Replace control board
Red LED(s) Illuminated
(surge protected models only)
Surge protection has been damaged and is no longer
functional.
Replace control board assembly.
(Contact Progressive Dynamics service department for correct control board assembly)
See website www.progressivedyn.com
for more troubleshooting information and return instructions



