Project Timber Evolution My Den 8x6 - Page 16

50mm
Screws
Position and fix
the Gable Frames
44mm x 27mm
x 2050mm
(2)
Side
Back
SideFront
Pilot drill holes
before fixing
GABLE - Roof Stand-Off Frame (SOF)
ID: PT21074
50mm
Screws
Back
Position and fix the
Drip Edge Flashing
Drip Edge Flashing Stages
Pilot drill holes
before fixing
ID: 21173
50mm
Screws
Back
Position and fix
the Rear Frame.
44mm x 27mm
x 2475mm
(1)
REAR - Roof Stand-Off Frame (SOF)
Pilot drill holes
before fixing
ID: PT21074
Drip Edge Flashing Length Size
Building size
8x6
L2530mm x 1
Drip Edge Flashing Lengths
Back View
Side
Back
Drip Edge
Flashing
Gable
Frame
Drip Edge Flashing position
47
50
51
48 49
