Project Timber Evolution My Den 8x6 - Page 3

Door Position (LEFT)
Door Position (RIGHT)
Door and Front Windows position options
Single Door Panel
(LEFT)
Glazing Units
(610mm)
Single Door Panel
(RIGHT)
Glazing Units
(610mm)
To p
Panel
Bottom
Panel
To p
Panel
Bottom
Panel
IMPORTANT: Always check the internal lining corner gap of the panels
2135mm
1220mm
Side Window
Opening Panel
(LEFT)
Diagram
ID: PT25521
1220mm1220mm
585mm
(LOW)
585mm
(LOW)
1220mm
(HIGH)
610mm
610mm
Side
Window
Opening
position
(LEFT)
Door
Position
RIGHT
Floor Plan
Front of Building
Front
Left Side
Side Opening Window (LEFT)
position option
