Project Timber Hobbyist - Page 14

For OSB Roof Sheet ONLY
For Tongue and Groove Roof Panel ONLY
OSB Roof fixing
Repeat previous
stages until the
OSB roof sheet
are complete.
Front
30mm
Nails
Soffit fixing
Secure in place the
soffit to the roof panel
30mm
Screws
Pilot drill holes
before fixing
Tongue and Groove Roof Panel fixing
Position the roof panel to the
top of wall panels and purlins
Front
Back
Soffit fixing
Position the soffit to the front
of tongue and groove roof panel
Front
Back
*11mm x 45mm x 1172mm
*11mm x 45mm x 879mm
25
26
27 28
