Project Timber Hobbyist - Page 16

Window Glaze fixing
Place the Glazing into Window
Panel and fit the Beading on both
sides. Fit the rest of the Glazing
and Beading to the Window
Panel
Use Cardboard
to protect the
Glazing when
fitting the
Beading
Panel
Pins
Door Fixing
Fix the hinges to the
doors over braces
30mm
Screws
Window Sill fixing
Position the window sill
to the window panel
Tower Bolt Lock fixing
30mm
Screws
Turn Button Lock fixing
Bottom
To p
30mm
Screws
Door Fixing
30mm
Screws
34
37
38 39
35 36
