CONNECTORS / STECKER / CONNECTEURS / CONECTADORES / CONNETTORI / KONTAKTER
S-Video G/Y Computer DVI-I Computer VGA RS-232 RC LAN
4 PIN MINI DIN FEMALE
PHONO/RCA
FEMALE
DVI-I
15 HIGH DENSITY
DSUB FEMALE
9 PIN DSUB FEMALE
3,5mm stereo
mini jack
RJ 45
1 GND STEM GREEN: G/Y 1 TMDS Data 2- 1 Analog R in 1 NC TIP: 5V DC 1TX+
2 GND SHIELD: GND 2 TMDS Data 2+ 2 Analog G in 2 RXD RING: SIGNAL 2TX-
3 Luma 3 TMDS Data 2/4 Shield 3 Analog B in 3 TXD STEM: GND 3RX+
4 Chroma 4 Not used 4 AGND 4 NC 4GND
5 Not used 5 AGND 5 GND TRIGGER 5GND
6 DDC Clock 6 Analog R GND in 6 NC
3,5mm stereo
mini jack
6RX-
7 DDC Data 7 Analog G GND in 7 NC 7GND
8 Analog Vertical Sync 8 Analog B GND in 8 NC 8GND
C-Video B/Pb 9 TMDS Data 1- 9 Reserved
PHONO/RCA FEMALE PHONO/RCA FEMALE
10 TMDS Data 1+ 10 Sync GND in HDMI
11 TMDS Data 1/3 Shield 11 AGND
HDMI
STEM YELLOW: STEM BLUE: B/Pb 12 Not used 12 DDC/SDA
Composite SHIELD: GND 13 Not used 13 H Sync in 1 TMDS Data 2 +
SHIELD: GND 14 +5V Power 14 V Sync in 2 TMDS Data 2 Shield
15 DDC/SCL 3 TMDS Data 2 -
C1 Analog Red 4 TMDS Data 1 +
C2 Analog Blue 5 TMDS Data 1 Shield
R/Pr C3 Analog Green 6 TMDS Data 1 - USB
PHONO/RCA FEMALE
C4 Analog Horiz. Sync 7 TMDS Data 0 +
DIGITAL USB
C5 Analog GND Return 8 TMDS Data 0 Shield
STEM RED: R/Pr 9 TMDS Data 0 - 1 VCC
SHIELD: GND 10 TMDS Clock + 2 -Data
11 TMDS Clock Shield 3 +Data
12 TMDS Clock - 4 GND
13 CEC
14 Not Used
15 DDC Clock
16 DDC Data
17 Ground
18 +5V Power
19 Hot Plug Connect
20 Shell
TECHNISCHE DATENTECHNICAL DATA DONNÉES TECHNIQUES DATOS TÉCNICOS
