Reversing the door
This refrigerator has been built with the door hinges on the right. If you wish to
change the opening direction, follow the instructions below:
1. Remove the upper hinge cover (6) first.
2. Remove the two screws (1) that hold the upper hinge (5) (right side) to the fridge
body. Remove the upper hinge (5).
3. Lift the door and place it on a padded surface to prevent scratching it.
4. Reverse the hole cover plate (7) from the left side to the right.
5. Remove the two screws (8) that hold the lower hinge (2) and remove the lower
hinge (2).
6. Remove the left front foot (4) and transfer it to the right side.
7. Before fitting the lower hinge (2), swap over the hinge pin (9) and the foot (3) to
the other side of the lower hinge (2). Then install the lower hinge (2) onto the left
side of the lower frame with two screws (8).
8. Position the door in place making sure the door seats onto the lower hinge (2).
9. Align the door in the closed position, secure the upper hinge (5) in the top fame on
left side with two screws (1). Remember, do not tighten the two screws (1) until
the top of the door is leveled with the top of the fridge.
10. Install the upper hinge cover (6) on the upper hinge.
FIGURE 1 - REPRESENTATIVE POSITION OF COMPONENTS PRIOR TO
DOOR REVERSAL.
FIGURE 2 - REPRESENTATIVE POSITION OF COMPONENTS AFTER DOOR
REVERSAL.
7
