Air intake
Figure (2)
mini 50 mm
mini 20 mm
screw
bracket
base
screw hole
mini 760 mm
5
Make sure the ceramic h
ob is well ventilated and the air inlet and outlet are not
blocked.
Ensure the ceramic hob is installed as shown in Figure (2)
Note: The s
afety distance between the ceramic hob and the cupboard above the
hotplate should be at least 760mm.
Fix the hob on the table by tightening the four brackets on the bottom of the hob
(see picture). Adjust the bracket position to suit for different table top thickness.
