88
NOTE :
After completing connection, turn on the tap slowly and make sure there are no
leak.
Do not twist, squash, modify or cut the hose.
Connecting the drain hose
To connect the drain hose, please use one of the following methods.
Make sure that the drain hose is not bent, crushed or extended.
• Put the hose into a drain hole.
When installing the drain hose to a
sink, secure it tightly with a string.
When installing the drain hose to the
laundry tub, proper securing of the
drain hose will protect the oor from
damage due to water leakage.
Drain hole
Max.100cm
Min.60cm
• Connect the drain hose onto a
sink outlet spigot securely.
The drain hose
should not be placed
higher than 100 cm
above the oor.
Water in the
appliance does
not drain or drains
slowly if above this
height.
Laundry tub
Hose
retainer
Max.100cm
Min.60cm
Min.60cm
Max.100cm
Tie
strap
To Next Page
