Display Function
LOAD and
BATTERY
CAPACITY
LEDs
These LEDs show the load of the UPS system if the mains power is
available (normal operation):
2nd LED 96%-105 % 3rd LED 76%-95 %
4th LED 56%-75 % 5th LED 36%-55 %
6th LED. 0-35 %
In the battery operation, the LEDs indicate the capacity of the
batteries:
2nd LED 0-25 % 3rd LED 26%-50 %
4th LED 51%-75 % 5th LED 76%-95 %
6th LED 96%-100 %
