8. Technical Data
8.1 Electrical specifications
INPUT
Model No. UPS T1000(S)
UPS T2000 UPS T2000S
UPS T3000(S)
Phase Single
Frequency (46~54)Hz
Current(A) 7A 9A 12A 16A
OUTPUT
Model No. UPS T1000(S) UPS T2000(S) UPS T3000(S)
Power rating 1kVA/0.7kW 2kVA/1.4kW 3kVA/2.1kW
Voltage 220/230/240 ×（ 1 士 2% ） VAC
Frequency 50 ×（ 1 ± 0.2 ） Hz (Battery mode)
Wave form sinusoidal
BATTERIES
Model No. UPS T1000 UPS T2000 UPS T3000
Number and type
3 × 12V 7.2Ah 8 × 12V 7.2Ah 8 × 12V 7.2Ah
8.2 Operating Environment
Ambient Temperature 0
o
C to 40
o
C
Operating humidity < 95%
Altitude < 1000m
Storage temperature 0
o
C ~ 40
o
C
8.3 Typical stored energy time (Typical values at 25°C in minutes:)
Model No. 100 % Load 50 % Load
UPS T1000 5 14
UPS T2000 9 21
UPS T3000 5 15
