Overview2
EN2
LED
Number DescriptionLED
Power
2.4G/5G
1
2
WPS3
LAN 1-44
WAN5
ON - Device is powered on
OFF - Device is powered o
ON - Wireless link established and active
OFF - Wireless is turned o
Blink - Wireless packet being transmitted
OFF - Idle
Blink - WPS is being triggered
ON - LAN link established and active
OFF - No LAN Link
Blink - LAN ethernet packet being transmitted
ON - WAN link established and active
OFF - No WAN Link
Blink - WAN ethernet packet being transmitted
Number DescriptionPorts/Buttons
WAN6
LAN 1-47
The WAN port is to connect to the broadband access
device. Usually connect to DSL / Cable modem, or to
network switch at home/ oce
The LAN ports to connect local PC/Laptop to the router
Power8 Power socket to connect the power adapter
Power Button9 Power ON / OFF SWITCH
WPS10
Press this button for at least 3 full seconds and the
WPS LED will start blinking to start WPS
Reset11
Press this button for at least 10 seconds to Reset
device to its default settings
Ports/Buttons
Note:
The illustrations in this document may appear dierent from your model.
English
