PROLiNK PRN3006L - Hardware Installation

EN 2
1. Overview
1. Antenna
2. Power Button
3. DC Input
4. LAN Ports
5. Telephone Port
(Optional – only available on PRN3006L with voice)
6. Reset Button
7. WPS Button
8. SIM Card Slot
Step 1: Hardware Installation.
1. Insert the SIM Card into the slot per the direction shown in the bottom case of the
PRN3006L.
Notes:
• Usage of Micro/Nano-SIM card with unofcial adapter is not recommended.
• Inserting SIM Card while the PRN3006L is powered on is not recommended.
STEP 1
Hardware Installation
STEP 2
Web Conguration
2. Installation
Rear View Bottom View
1
2
3 4
5
6 7 8
