PROLiNK PWN3702P User Manual

4. Connecting to the Root AP
EN 4
Step 1. Plug the PWN3702P into the electrical socket and power on the electrical socket. The Power
LED on PWN3702P will illuminate. Wait until the WLAN and WPS LEDs light up.
Step 2. Press the Wi-Fi Protected Setup (WPS) button on your wireless router or root AP.
Step 3. Press the WPS button of PWN3702P for 1 second until the WPS LED starts to blink.
Note 1. The Signal Strength LEDs will illuminate to show the link quality once connected to
the root AP.
Note 2. Both buttons must be pressed within 2 minutes.
Method 1 : With WPS button
LOCATION 1
LOCATION 2
2
Minutes
2 seconds
Within 2 Minutes1 second
WPS
WPS
WPS
Wireless Router
PWN3702P
