·If the desktop is from our brand, please
put the frame on the desktop, adjust the
distance between crossbar ends and align
them with the holes.
·If the desktop is from other brand, put the
frame on the axis on the desktop and
adjust both lifting columns to proper
positions.(It’s recommended that the
distance between the side bracket and the
edge of the desk be 5cm.)
·For the desktop from our brand, please
secure the frame and desktop with 7
M6*1*14 Machine Screw socket head cap screws.
·For the desktop from other brand, please
secure the frame and desktop with 7
ST5*0.8*20 tapping screws.
STEP 5: Assemble the Frame and the Desktop
P7
H5
×7
H3
ST5*0.8*20
Tapping Screw
×7
H1
×1
OR
M6*1*14
Machine Screw
M4 Allen Wrench
Hardware List Hardware List
