Prology CMD-150 - DISMANTLING INSTRUCTIONS; Step 1-4: Component Removal

2-1
DISMANTLINGINSTRUCTIONS
2-1
R
PulloutFPC
wire.
2emovetopandbottomcovers.
4 RemoveCDloader
1Pullouttheshortsheetfrommainset.
3Loosen4pcsscrewtoremoveFrontCabinet.
Remove1pcsscrew
ontheleftsideof
FrontCabinet.
Remove2pcsscrew
frommetalside.
Remove1pcsscrew
fromFrontCabinet.
Remove2pcsscrew
todismantlethedeck.
Loosen8pcsscrew
toremoveheatsink&
TopCover&Bottom
Cover.
Remove1pcsscrew
frommetalside.
Remove2pcsscrew
frommainboard.
