REV 1.0 / PL-QCK-WSENSOR/VC2000-EN 5
COM
THERM
COM
POT
4.96”
(126 mm)
1.30”
(33 mm)
3.23”
(82 mm)
Schedule override
Room temperature
Setpoint (10K)
Temperature table (thermistor: 10K Type 3)
Fahrenheit 41 50 59 68 77 86 95 104
Celsius 5 10 15 20 25 30 35 40
Ohms 25395 19903 15714 12493 10000 8056 6530 5324
