Prolon PL-RS - Digital Sensor (PL-T200); Dimensions and Wiring

REV 1.0 / PL-QCK-WSENSOR/VC2000-EN6
Digital Sensor (PL-T200)
Dimensions and Wiring
INT A (+)
INT B (-)
24VAC
COM
4.96”
(126 mm)
1.30”
(33 mm)
3.23”
(82 mm)
Schedule override
(hold for 3 second)
Communication (RS485)
Power (2 VA max)
RJ45 connection
(to C1000)
